Machine Maintenance Procedures 3-27
Mainboard Installation 0
1. Place the mainboard onto the base assembly. Refer to Figure 3-25.
2. Install and secure two (2) screws (C) to mainboard. Refer to Figure 3-24.
3. Connect IO Board FPC to mainboard connector (F) (Figure 3-24).
4. Connect DC-in cable to mainboard connector (E) (Figure 3-24).
5. Connect LVDS cable to mainboard connector (D) (Figure 3-24).
6. Connect the speaker cable to mainboard connector (B) on the backside of the
mainboard (Figure 3-23).
7. Install Upper Case.
ID Size Quantity Screw Type
CM2.5*4 2
