Acer e-mill 3VS - Page 22

- 21 -
E-MILL 3VS, 3VSII MACHINE SPECIFICATIONS:
Range
Table Travel (X-axis)
42” Table: 24”/
610mm
49” Table: 28”/
711mm
Saddle Travel (Y-axis)
12 in. (305mm)
Quill Travel
5 in. (127mm)
Knee Travel (Z-axis
manual)
16 in. (406mm)
Ram Travel
12 in. (305mm)
Throat Distance (min.)
4
1
/
4
in. (171mm)
Throat Distance (max.)
28
1
/
4
in. (476mm)
Table to Spindle Nose
Gage line (min.)
1 in. (25.4mm)
Max. Weight of Workpiece
750 lbs. (340 kgs.)
Table
Overall Sizes
9 x 42 in. (229 x
1067mm)
9 x 49 in. (229 x
1245mm)
T-Slots
3 on 2
1
/
2
in. (64mm)
centers
T-Slot Size
5
/
8
in. (16mm)
Height above floor (max.)
48 5/8 in. (1235mm)
Milling
Feed Rate (Power
Optional)
Please see Chart
Space and Weight
Floor Area
7 x 10 ft. (2.1 x
3.1m)
Height
87 in. (2210mm)
Net Weight
2330 lbs. (1060kgs)
2380 lbs. (1080kgs)
Shipping Weight
2530 lbs. (1150kgs)
2580 lbs. (1173kgs)
Power
Electrical Supply – 60/50
Hz.
3 phase
220/230/380/415/
440/460/575V
Color
Standard
Machine Gray/ACER
White with Burgundy
Stripes
