- 26 -
e-mill 5VK
A
B
C
D
E
F
Min.
-
-
2"
-
2 1/4"
-
-
50mm
57mm
Max.
-
-
-
22 1/2"
-
23 3/4"
-
-
-
572mm
-
603mm
Figure 4. Principal Dimension of 5VK
