- 27 -
E-MILL 5VK MACHINE SPECIFICATIONS:
Range
Table Travel (X-axis)
50” Table: 27”/
686mm
54” Table: 31”/
787mm
Saddle Travel (Y-axis)
17 in. (432mm)
Quill Travel
5 in. (127mm)
Knee Travel (Z-axis
manual)
19 in. (483mm)
Ram Travel
24 in. (610mm)
Throat Distance (min.)
4
1
/
4
in. (171mm)
Throat Distance (max.)
28
1
/
4
in. (476mm)
Table to Spindle Nose
Gage line (min.)
4 in. (100mm)
Max. Weight of Workpiece
850 lbs. (386 kgs.)
Table
Overall Sizes
10 x 50 in. (254 x
1270mm)
10 x 54 in. (254 x
1372mm)
T-Slots
3 on 2
1
/
2
in. (64mm)
centers
T-Slot Size
5
/
8
in. (16mm)
Height above floor (max.)
51
5
/
8
in. (1311mm)
Milling
Feed Rate (Power
Optional)
Please see Chart
Space and Weight
Floor Area
7 x 10 ft. (2.1 x
3.1m)
Height
96 in. (2439mm)
Net Weight
3750 lbs. (1705kgs)
3900 lbs. (1773kgs)
Shipping Weight
3949 lbs. (1795kgs)
4099 lbs. (1863kgs)
Power
Electrical Supply – 60/50
Hz.
3 phase
220/230/380/415/
440/460/575V
Color
Standard
Machine Gray/ACER
White with Burgundy
Stripes
