Chapter 6 66
9 MOTHERBOARD 1 25 MERLOT-DECORATE-D 1
10 SHEETMETAL-BOTTOM-
CONSUMER
1 26 MERLOT-DECORATE-C 1
11 MERLOT-CONSUMER-WITH-TV 1 27 MERLOT-ODD-BUTTON 1
12 MERLOT-DECORATE-A 1 28 ODD SUPPORT 1
13 MERLOT-DOWN-COVER 1 29 ODD-COVER 1
14 FOOT-RUBBER 4 30 SCREW M2×2 4
15 MERLOT-IR-LENS 1 31
SCREW 3×6
9
16 SPRING-POWER-BUTTON 1 32 MERLOT-DECORATE-B 1
ITEM NAME
Q’TY
ITEM NAME
Q’TY
