4 I-210+ User Manual
Physical Description
The I-210+ meter is furnished with a standard UV stabilized polycarbonate cover.
The sides of the cover are designed to be reflective to minimize solar heating and
obscure the internal components of the meter. Other cover options are available on
request.
The meter base assembly contains current sensing CTs and the necessary potential
connections to configure the meter for specific applications. The meter base
configuration is set in the factory and not designed for field modification (except
for 5th terminal location). The I-210+ is available with optional potential test links
in forms 2S and 12S.
The Liquid Crystal Display (LCD) indicates energy consumption and optionally
instantaneous demand or voltage on the lower three-digit informational display.
The display is soldered directly to the meter circuit board for high reliability. The
display features are covered in detail
AMR options may be installed on a supporting plastic bridge which mounts into
the meter base, or they may be mounted in the Nameplate Carrier itself, depending
on the size and construction details of the specific option.
A configuration port is located at the 3 o’clock position of the meter face. The port
is used in conjunction with a reset adapter that mounts over the cover and
MeterMate software (version 5.41 or greater) to reset accumulated energy to zero.
The port is intended for factory or shop use and is not designed for use in direct
sunlight. (Please see Configuration Port on page 19 for more information.)
Operating Range and Ratings
The operating attributes along with their values are listed in the following table:
Attribute Value
Voltage 120/240V (±20%)
Operating Temperature (under the cover) -40°C to +85°C
LCD Operating Temperature -30°C to +80°C
Storage Temperature -40°C to +85°C
Relative Humidity 95% non-condensing
Frequency 50 or 60Hz
Power Consumption (excluding modules) <0.7 watts
Accuracy
Class 0.5 per ANSI C12.20, but typically
Current Class 20, Class 100, Class 200, Class 320
Enclosure
Durable UV stabilized polycarbonate
