I-210+ User Manual 29
Chapter 5 • Upgrading
AMI Module Installation
To learn more about the various modules compatible with the I-210+ and I-210+n
meter and how to install those modules, please contact the module supplier for the
appropriate integration documentation.
C
AUTION
Do not interchange base and electronics module assemblies between meters.
Calibration data stored in the meter is particular to a set of current sensors
and electronics module. Interchanging these components causes the meter to
lose calibration and revert to an unconfigured mode which is indicated by
on the LCD.
Meter Reassembly
1. Carefully align the module over base assembly posts and push down firmly
to engage all four snaps on the post undercuts.
2. Connect the CT sensor connector to the socket on the electronics module.
3. Replace the cover by aligning it with the openings in the base and rotating it
clockwise approximately 30 degrees.
4. Install security seals as required.
