I-210+ User Manual 5
Chapter 2 • Product Description
Meter Forms
The I-210+ meter is available in several variant forms, which can be selected
depending upon the application. The ANSI Standard S Base (socketed) Meter
Forms are shown in the table below.
ANSI Standards
The performance of the I-210+ meter meets or exceeds the following industry
standards: ANSI C12.1, C12.10, C12.20, and all standards incorporated by
reference.
Form Wires Circuit Elements SC/TR Class Voltage
1S 2 1Ø 1 SC 100 120
1S 2 1Ø 1 SC 100 240
2S 3 1Ø 1 SC 100 240
2S 3 1Ø 1 SC 200 240
2S 3 1Ø 1 SC 320 240
3S 2 1Ø 1 TR 20 120
3S 2 1Ø 1 TR 20 240
4S 3 1Ø 1 TR 20 240
12S 3 Network 2 SC 200 or 320 120/208
12S 3 3Ø 2 SC 200 or 320 240
25S 3 Network 2 SC 200 or 320 120/208
