VECTOR CONTROL AND MOTORS 8-1

SB1391 Hardware and Setup Guide - Document revision no. 1.14

8. VECTOR CONTROL AND MOTORS

8.1. Vector Control for DC Brushless (AC Servo/AC

Synchronous)

All ACS-Tech80 digital control modules use the Vector Control method to "convert" a simple low

cost DC brushless(AC servo/AC synchronous) motor, equipped with position feedback device,

into a high performance servo motor.

Note

The diagrams in this section are for general description purposes only.
