WORKING WITH THE CONTROL UNIT 5-15
SB1391 Hardware and Setup Guide - Document revision no. 1.14
Enable signal
External
amplifier
Polarity of amplifier's enable signal
Commutation
by
External
amplifier
Controller - the commutation is done by the control unit. The
control unit generates a two-phase current reference. The
amplifier generates the third phase reference.
Amplifier - the commutation is done by the amplifier. The
control unit outputs a single current command.
Action Effect of action
7. Click the OK tool button
.
The new amplifier is added to the amplifier database.
5.2.5. Adding a Motor to the Adjuster Database
Note
Some types of motors have more than one name. ACS-Tech80 uses
the following motor terminology:
Term used Alternative name
AC induction Three-phase AC asynchronous, squirrel cage
DC brushless
T
hree-phase
AC servo, AC synchronous
If the system's motor is not in the database yet, it should be added now.
Action Effect of action
1. On the Database menu, point to
Motors, and then click Add item
as shown in FIGURE 5-12.
The first time that the motor database is accessed, the
message in FIGURE 5-13 appears, to prevent the
default motor database from being overwritten.
To Next Page
