2) Sectorial panoramic with improved orthogonality
· Full scan
· Right side only
· Left side only
3) Frontal panoramic
4) Bitewings
5) Frontal temporomandibular joint with closed or open mouth
· Both sides
· Left TMJ only
· Right TMJ only
6) Lateral temporomandibular joint with closed or open mouth
· Both sides
· Left TMJ only
· Right TMJ only
7) Frontal maxillary sinuses
8) Lateral maxillary sinuses
· Left sinus only
· Right sinus only
CBCT group
The CBCT group includes all the 3D CBCT examinations of the dental and maxillofacial regions.
Here below the size of the reconstructed volumes expressed as diameter x height.
1) Dental FOV
· 40mm x 40mm
· 60mm x 60mm
· 80mm x 80mm
· 110mm x 80mm
NOTE :
A specic version of AIS software disables FOV 110mm X 80mm
2) ENT FOV – Nose
· 110mm x 80mm
NOTE :
A specic version of AIS software disables FOV 110mm X 80mm
3) ENT FOV – Ear
· Left ear only, 60mm x 60mm
· Right ear only, 60mm x 60mm
Cephalometric group
• Frontal (AP/PA)
• Lateral (LL)
• Hand acquisition (Carpus - special support needed)
For all examination groups, the operator set the predened loading factors, in terms of X-ray anodic current and X-ray tube
voltage, by selecting the patient type between the following options:
· MAN
- small
