Acteon X-MIND trium - Specific Trium Error Messages

46
USER MANUAL• X-Mind trium • (13) • 03/2018 • NTR0EN010M
ENGLISH
10.2 TRIUM ERRORS
CODE Ser Message / Description Act Solution
0 C
CHECK INTERNAL ETHERNET
Hw errror: Main board and ETHERNET
switch do not communicate
In this condition X-MIND trium and
workstation cannot communicate;
THIS ERROR APPEARS ONLY ON THE
X-MIND trium DISPLAY.
U/T
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
If error remains technical service is required.
13 C Image detector not grabbing U/T
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
if error remains, in case of CEPH or PAN detector, detach it
from the equipment and attach it again, ascertaining to lock
it correctly:
if error remains technical service is required.
66 E
"CONFIG_INFO_UPDATED
Conguration data have been
updated"
U/T
Restart X-MIND trium and workstation in order that
modications will be effective.
67 D
"MOTOR_AXES_DO_BREAK
WARNING: operator has intentionally
stopped a movement releasing XRay
button"
U
Wait that the full exam procedure is completed before
releasing X-ray button: on the workstation will appear the
message “exposure button can be released”.
68 B
"MOTOR_AXES_CNTL_FSM
Unexpected motors FSM condition"
A
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation.
69 C
"MOTOR_AXES_TRJ_LOAD
Trajectory loading from PC is failed"
A
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation.
70 C
"XRAYS_DISA_ETH_LINK
Xrays disabled due to ETH connection
failure"
U/T
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
If error remains technical service is required.
71 C
"XRAYS_DISA_PC_ALARM
Xrays disabled due an alarm issued
from PC"
U/T
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
If error remains technical service is required.
72 C
"PCDRV_COMM_WDOG_ERR
PC communication timeout"
U/T
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
Try to disable anti-virus and rewall
If error remains technical service is required.
73 B
"X_AXIS_ERR_RES_RAMP
Unexpected FSM condition during
X-axis reset"
A
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
74 C
"X_AXIS_ERR_RES_TOUT
X-axis reset timeout (Uarm movement
parallel to the wall)"
U/T
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
If error remains technical service is required.
75 B
"Y_AXIS_ERR_RES_RAMP
Unexpected FSM condition during
Y-axis reset"
A
Reset error from AIS software on workstation;
if error remains restart X-MIND trium and workstation;
