ANNEXES
11.1 DEVICE POWER SUPPLY
Type of power supply Single-phase alternating current power supply
Supply voltage 100 – 240 V
Maximum voltage variation ±10%
Frequency 50 – 60 Hz
Absorbed current (@ 90 kV, 10 mA) 7 A (@ 240 V)
15 A (@ 100 V)
Standby current 1 A
Maximum absorbed power 1500 VA
Line fuses T 250 VH 10 A (for power supply range: 200 – 240 V)
T 250 VH 20 A (for power supply range: 100 – 200 V)
Apparent resistance 0.2 Ω
11.2 ELECTRICAL CLASSIFICATION (IEC 60601-1)
Protection against electrical shock (insulation class) Class I
Degree of protection against electrical shock (Applied part) TYPE B
Use with ammable anaesthetics Not evaluated for use in presence of ammable anaesthetic
mixture with air, oxygen or nitrous oxide
Sterilization and disinfection methods The device is supplied not sterile and it must not be subjected
to sterilization
Operation mode Continuous operation with intermittent X-ray loading
Installation type Permanently Installed (xed installation)
11.3 X-RAY ASSEMBLY AND X-RAY TUBE
X-RAY TUBE MODEL CEI OPX/105
Nominal High Voltage 60 – 90 kV
Anode Material Tungsten
Anode thermal capacity 30 kJ
Focal spot size (IEC 60336) 0.5 mm x 0.5 mm
Target angle 5°
