11.10 LASER
Laser type Line Wavelength Operating
voltage
Class Diffractive
optics
Power Positioning
accuracy
PAN mid-sagittal
from patient arm
Single line 635-650 nm 2.7 to 5 V 1M Line, 90° 0.3 mW <1mm
Canine
from Tubehead
Single line 635-650 nm 2.7 to 5 V 1M Line, 90° 0.3 mW <1mm
Frankfurt
from Tubehead
Multi-line 635-650 nm 2.7 to 5 V 3R Line, 90° 0.3 - 2 mW <1mm
CBCT mid-sagittal
from U-arm
Single line 635-650 nm 2.7 to 5 V 1M Line, 90° 0.3 mW <1mm
CBCT coronal
from Tubehead
Single line 635-650 nm 2.7 to 5 V 1M Line, 90° 0.3 mW <1mm
Axial (horizontal)
from Tubehead.
Single line 635-650 nm 2.7 to 5 V 1M Line, 90° 0.3 mW <1mm
11.11 FIRMWARE DATA
Main board 0.44.3
Power board 0.10.3
Inverter board 2.4.0
AUX CBCT board 0.7.0
UX CEPH board 0.3.0
Image detectors 2.5.27
11.12 CLIENT PC MINIMUM REQUIREMENTS
IT’S MANDATORY TO RESPECT CLIENT PC MINIMUM REQUIREMENTS
THE CHOICE OF PC FOR AIS CLIENT, IS UNDER CUSTOMER RESPONSIBILITY. A WRONG
CHOICE, WITHOUT RESPECTING MINIMUM REQUIREMENT, WILL NOT BE UNDER ACTEON
GROUP RESPONSIBILITY.
Please, take care about workstation minimum requirement to avoid faults, errors, misfunctionality and/or problem during
the installation, connection and use of X-MIND Trium.
CLIENT:
WINDOWS OS BASED HARDWARE
Processor: Intel I5 or I7 (notebooks), Quad Core suggested (for Workstations)
RAM: minimum 4 GB, for big FOV DICOM stacks it is suggested to install 8 GB
Hard disk: minimum 300 GB (for image storage, the software alone occupies 200 MB, the full implant library is 7 Gb size)
Graphic card: Nvidia Geforce product range with 1 Gb dedicated RAM (notebooks) or Nvidia Quadro with dedicated memory
(workstations)
Screen resolution: minimum height 1024 and width 1600, it is suggested to use higher resolutions for optimal planning (full
HD: 1920 x 1080)
O/S: Windows 7 (64 bit), Windows 10 (64 bit).
MAC OS BASED HARDWARE
