Acteon X-MIND trium - Degree of Protection Provided by Enclosures

57
ENGLISH
USER MANUAL• X-Mind trium • (13) • 03/2018 • NTR0EN010M
Current-time product accuracy ± (10% + 0.2 mAs)
8
Dose reproducibility
9
<0.05
Maximum anodic current 10 mA (typical 8 mA)
Loading factors related to the maximum specied energy
input in one hour
Continuous mode: 85 kVp @ 10 mA
Nominal X-ray Tube Voltage together with the highest X-ray
Tube Current obtainable from the High-Voltage Generator
when operated at that X-ray Tube Voltage
Pulsed mode: 90kVp @ 10 mA
Highest X-ray Tube Current together with the highest X-ray
Tube Voltage obtainable from the High-Voltage Generator
when operating at that X-ray Tube Current
Pulsed mode: 10 mA 90 kVp
The Combination of X-ray Tube Voltage and X-ray Tube
Current which results in the highest electric output power
Pulsed mode: 90 kVp @ 10 mA
The lowest Current Time Product or the combinations of
Loading Factors resulting in the lowest Current Time Product
0.04 mAs per frame
Nominal electrical power 1.1 kW @ 90 kV, 10 mA, 0.1 s loading time
X-ray emission technology/ mode of operation DC High Frequency
PAN/CEPH:
- Continuous X-ray loading.
- Combinations of kV and mA along the whole maximum
exposure time. (Maximum combination of loading factors in
continuous mode is 85 kV @ 10 mA).
CBCT:
- Intermitting X-ray loading.
- Combinations of kV and mA with a maximum combination
of loading factors: 90 kV @ 10 mA.
Loading factors for Leakage radiation measurement 90 kVp @ 10 mA
Focal Spot-to-Skin distance
10
≥ 150 mm
1
IEC 60601-1-3 Par. 7.1 - 21 CFR 1020.30 (m)
2
IEC 60601-1-3 Par. 7.1
3
21 CFR 1020.30 (k)
4
IEC 60601-2-63 Par. 203.6.4.3.102.2 – 21 CFR 1020.31 (a) (4)
5
IEC 60601-2-63 Par. 203.6.4.3.102.3 – 21 CFR 1020.31 (a) (4)
6
IEC 60601-2-63 Par. 203.6.3.1.101 – 21 CFR 1020.31 (c)
7
IEC 60601-2-63 Par. 203.6.4.3.102.4 – 21 CFR 1020.31 (a) (4)
8
IEC 60601-2-63 Par. 203.6.4.3.102.5 – 21 CFR 1020.31 (a) (4)
9
IEC 60601-2-63 Par. 203.6.3.2.101 – 21 CFR 1020.31 (b)
10
IEC 60601-2-63 Par. 203.9 – 21 CFR 1020.31 (f)
11.4 DEGREE OF PROTECTION PROVIDED BY ENCLOSURES
According to the standard IEC 60529, the degree of protection is IP20
