11.5 DEVICE MECHANICAL DATA
Dimensions Footprint: Max 1505 x 1715 mm
Height: 2358 mm
Weight PAN: 170 kg
PAN/CBCT: 185 kg
PAN/CBCT With CEPH: 215 kg
Mechanical conguration Wall mount / Self standing
Left column/Right column
Patient position: Standing, seated or on wheel-chair
11.6 WORKSTATION FEATURES
CBCT
WORKSTATION PROVIDED BY THE MANUFACTURER
CPU 6th Gen Intel(R) Core(TM) i5-6500 (Quad Core 3.2GHz)
Hard Disk 1 TB
Graphic Processor NVIDIA (CUDA environment GPU family)
Like :
Quadro P2000
RAM 8 GB
NIC Dedicated Gb Ethernet for X-MIND Trium Connection
Operating System Windows 7 Professional 64 bit.
Certications IEC 60950-1, CISPR 22, CISPR 24
PAN/CEPH
MINIMUM REQUIREMENTS
CPU INTEL I5 or superior
Hard Disk 1TB 7200 rpm or superior
Graphic Processor OPEN GL 2.1 compatible (suggested an NVIDIA GT/GTX)
RAM 8 GB
NIC INTEL CT 1000 pro
Operating System Windows 7 Professional 64 bit or
Windows 10 Professional 64 bit
11.7 DETECTORS
PAN/CEPH
Detector technology CMOS
Scintillator Direct deposition CsI
Manufacturer Hamamatsu Photonics K.K.
Model
PAN: FPD C10500D-43
CEPH: FPD C10502D-43G
Pixel size 100 µm
Active area
PAN: 148 mm x 6 mm
CEPH: 223,2 mm x 6 mm
