3
wiring, operation and maintenance.
Indicates that incorrect handling may result in death or severe injury.
Indicates that incorrect handling may result in medium or slight personal injury or physical damage.
Indicates “Prohibitions”(Indicates what must not be done.)
Indicates “Forced”.(Indicates what must be done.)
Installing and wiring
Do not connect the motor to the commercial power.
To prevent fire or malfunction.
Do not place the combustibles around the servo motor and drive.
To prevent fire.
Be sure to protect the drives through the case, and leave specified
clearances between the case or other equipment and the drive.
To prevent electric shock, fire or
malfunction.
Install it at the place free from excessive dust and dirt, water and oil mist
To prevent electric shock, fire ,
malfunction or damage
Install the equipment to incombustibles, such as metal.
To prevent fire.
Any person who is involved in wiring and inspection should be fully
competent to do the work.
To prevent electric shock.
FG terminal of motor and drive must be grounded.
To prevent electric shock.
Perform the wiring correctly after cut off the breaker.
To prevent electric shock, injury,
malfunction or damage
Have the insulation processing when connecting cables.
To prevent electric shock, fire or
malfunction.
Operation and running
During operation, never touch the internal parts of the drive.
To prevent burns or electric shock.
The cables should not be damaged, stressed loaded, or pinched.
To prevent electric shock, malfunction
or damage.
During operation, never touch the rotating parts of the servo motor.
To prevent injury.
Do not install the equipment under the conditions with water, corrosive
and flammable gas.
To prevent fire.
Do not use it at the location with great vibration and shock.
To prevent electric shock, injury or
fire.
Do not use the servo motor with its cable soaked in oil or water.
To prevent electric shock, malfunction
or damage
Operate the switches and wiring with dry hand.
To prevent electric shock, injury or
fire.
Do not touch the keyway directly when using the motor with shaft-end
keyway
To prevent injury.
Do not touch the motor and drive heat sink, as they are very hot.
To prevent burns or parts damaged.
Do not drive the motor by external drive.
To prevent fire.
Other safety instructions
Confirm the equipment’s safety after the earthquake happens.
To prevent electric shock, injury or
fire.
Installing and setting correctly to prevent the fire and personal injury when
To prevent injury, electric shock, fire,
