91
.
time
0
System alarm
After the
control power
supply is ON.
●Control circuit error
Restart control power
supply
1
EEP data error
●Parameter writing error
●After confirming cables, rewrite the parameters.
RESET signal (※)
2
Model code error
●Model code cannot be read.
●Confirm the combination of motor and drive.
●Please confirm the encoder cable.
Restarting control power
supply
4
Overspeed error
After the
servo is ON
●Position control and speed control error.
●Please adjust the parameters.
RESET signal (※)
5
Speed deviation
error
6
Position deviation
error
7
Overload error
8
Command
overspeed error
9
Encoder pulse
output frequency
error
●The encoder pulse output frequency is over 4Mpps
●Confirm the value of command division/multiplication
frequency
●Confirm the number of command pulse
12
Overheat error
●Overheat error of control circuit
●Reduce ambient temperature
●Set the drive in accordance with 「Installation direction
and clearances」
14
Overvoltage error
●Overvoltage error of control main circuit
●Confirm regenerative resistor warning by setting panel.
Please install a regenerative resistor if necessary.
15
Power supply error
●The voltage on the main circuit power supply is too low
or too high. If 200VAC error occurs, there is error after
the regenerative power is ON.
●Please confirm the 220VAC power supply cable and
distribution wiring of main circuit power supply
●Adjust 200VAC power input and servo ON time
according to timing chart. Confirm the regenerative
resistor warning signal on the setting panel. Please install
a regenerative resistor if necessary.
16
Encoder 1
After the
●The encoder data changes significantly in a sudden.
Restarting control power
