When your selection is successfully

completed, the display changes as

shown above, and then goes back to

the customize item screen.

If the ‘‘SETTING INCOMPLETE’’

message appears, go back to ‘‘AUTO

LIGHT SENSITIVITY’’ and repeat

the procedure again.

Press the SEL/RESET button to see

the selections.

Select the desired setting (MAX,

HIGH, MID, LOW or MIN) by

pressing the INFO ( / ) button,

then enter your selection by pressing

the SEL/RESET button.

Multi-Information Display
