Push a new bulb straight into the

socket until it bottoms, and

reinstall the socket into the light

assembly by turning it clockwise

until it locks.

Testthenewbulbtomakesureit

works.

Reinstall the light assembly cover.

Pull back the appropriate corner of

the trunk lid lining carefully.

Open the trunk.

Toreplaceabulboneitherside,

remove the two fasteners on the

left side, or a fastener on the right

side.

Lights

(in Trunk Lid)

Replacing a Back-up Light Bulb

436

FASTENERS

2010 TSX
