CONTINUED

Look for a blown wire inside the

fuse.Ifitisblown,replaceitwith

one of the spare fuses of the same

rating or lower.

Check the smaller fuses in the

under-hood fuse box and all the

fuses in the interior fuse boxes by

pulling out each one with the fuse

pullerprovidedonthebackofthe

under-hood fuse box cover.

Also check the combined fuse box in

the under-hood fuse box.

5.4.

Fuses

Taking Care of the Unexpected

477

BLOWN

FUSE PULLER

BLOWN
