Fig. 22: Removing The Steering Gear Box Mounting Bolts & Stiffener

38. Remove the steerin

earbox mountin

bracket bolts.

2004 Acura TSX

2004 AUTOMATIC TRANSMISSIONS Removal & Installation - TSX

Wednesday, March 12, 2008 9:44:47 PM Page 23
