Acura TSX 2004 Removal And Installation

19. Disconnect the ATF cooler hose (C) from the ATF cooler line (D), then plug the hose end.
20. Remove the ground cable (A), transmission upper mount bracket plate (B), and transmission upper mount
bracket (C).
Fig. 8: Removing The Ground Cable, Transmission Upper Mount Bracket Plate & Transmission
Upper Mount Bracket
21. Remove the harness clamp (A) and hose (B), and remove the bolts (C) securing the hose clamps. Remove
the mountin
g
nuts (D) and strut brace (E).
2004 Acura TSX
2004 AUTOMATIC TRANSMISSIONS Removal & Installation - TSX
Wednesday, March 12, 2008 9:44:47 PM Page 9
