Fig. 51: Aligning The Reference Marks With Edge Of Both Rear Stiffener

23. Tighten the mid-mount mounting bolts.

24. Install the rear mount base bracket bolts.

2004 Acura TSX

2004 AUTOMATIC TRANSMISSIONS Removal & Installation - TSX

Wednesday, March 12, 2008 9:44:48 PM Page 52
