Fig. 48: Support The Front Subframe With The Special Tool & A Jack & Lifting It Up To Body
19. Slide the steering gearbox (A) in the gearbox mounting bracket (B) on the subframe. Apply a soap and
water solution to the steering gearbox bushing (C) surfaces upper and lower. If you don't apply a soap and
water solution to the bushing surfaces, the gearbox bushing will be damaged when installing the
subframe.
2004 Acura TSX
2004 AUTOMATIC TRANSMISSIONS Removal & Installation - TSX
Wednesday, March 12, 2008 9:44:48 PM Page 49
