Fig. 39: Removing The Drive Plate & Washer From The Engine Crankshaft
2. Install the drive plate and washer on the engine crankshaft, and tighten the eight bolts in a crisscross
pattern in two or more steps.
TRANSMISSION INSTALLATION
1. Flush the ATF cooler (see ATF COOLER FLUSHING ).
2. Install the torque converter assembl
y
(A) on the mainshaft (B) with the new O-rin
g
(C).
