Acura TSX 2004 - Installing the Transmission Lower Mounts

76 pages

To Next Page

To Previous Page

Fig. 47: Installing The Transmission Lower Mounts

18. Support the front subframe (A) with the special tool and a jack, and lift it up to body.

2004 Acura TSX

2004 AUTOMATIC TRANSMISSIONS Removal & Installation - TSX

Wednesday, March 12, 2008 9:44:48 PM Page 48
