48. Install the ATF cooler hose (C) on the clamp (D) at the mark (E).
49. Connect the ATF cooler hoses (A) to the ATF cooler lines (B), and secure the hoses with the clips.
Fig. 70: Connecting The ATF Cooler Hose
50. Connect the 3rd clutch transmission fluid pressure switch connector (A), and install the harness clamp (B)
on the clamp bracket (C).
2004 Acura TSX
2004 AUTOMATIC TRANSMISSIONS Removal & Installation - TSX
Wednesday, March 12, 2008 9:44:48 PM Page 71
