Advanced RF Technologies, Inc.
55
8. ADXV SYSTEM-WIDE SPECIFICATION
700LTE/S8C/PCS/AWS
Parameters 700MHz SMR800+CELL PCS AWS
Frequency
(Bandwidth)
Downlink
Lower ABC+ Upper C
728-757MHz
862-894MHz
(32MHz)
1930-1995MHz
(65MHz)
2110-2180MHz
(70MHz)
Uplink
Lower ABC+ Upper C
698-716, 776~787MHz
817-849MHz
(32MHz)
1850-1915MHz
(65MHz)
1710-1780MHz
(70MHz)
Input Power
Range @
POI
Power Mode +48~ 0dBm
System
Gain/
Nominal
pass band
gain
Downlink
-11~33dB/43dB (2Watt)
-11~37dB/37dB (5Watt)
-11~43dB/43dB (20Watt)
-11~46dB/45dB (30Watt)
-11~46dB/46dB (40Watt)
Uplink 0~30dB
Rated mean output power
(DL)
43dBm(20W) 43dBm(20W) 46dBm(40W) 46dBm(40Watt)
Maximum Composite
Output Power(UL)
-15dBm
Noise Figure ≤ 5dB @maximum gain, Center Frequency
VSWR
≤ 1.3:1 @ BTS interface port
≤ 1.5:1 @ Internal interface port
Optical Loss 0~5dBo
System Delay < 2us
Spurious Meet FCC, 3GPP TS 36.104, 3GPP2 C.S0010-C
Dimension
(WXDXH)
Head End
Chassis
19in x 19.7 in x 7.0 inches
POI/POIL 1.3in x 17.0 in x 6.85 inches
ADXV-HPR
Chassis
19in x 15.0 in x 10.5 inches
ADXV-
HPR(Remote
Unit)
2.75in x 17.8 in x 10.3 inches
Weight
Head End
Chassis
20.9 lbs
POI 6.17 lbs
POIL 5.00 lbs
ADXV-
HPR(Remote
Unit) Chassis
17.60 lbs
