ADXV-
HPR(Remote
Unit)
13.22 lbs
Operating Temperature -22 - 140 F(-30~60°C)
Operating Humidity 5~90%RH
Power
Supply
Head-End
-48V DC
110/220V, 50-60Hz(optional) with battery backup function
ADXV-HPR
110/220V, 50-60Hz
-48V DC(optional)
Power
consumption
ADXV-H-NMS-
AC
8.85 Watt
ADXV-H-ODU-
4
7.47 Watt
ADXV-H-POI
7.20 Watt
ADXV-H-POIL
6.45 Watt
ADXV-HPR-
PSU-AC
5.4 Watt
ADXV-HPR-
ORU
109 Watt
ADXV-HPR-
437F
129 Watt
ADXV-HPR-
43S8C
145 Watt
ADXV-HPR-
46P
264 Watt
ADXV-HPR-
46A
259 Watt
Network Management
System
Ethernet(RJ45)
RF
connector
POI DIN(Female)
POIL 4.3-10(Female)
ADXV-
HPR(Remote
Unit)
4.3-10(Female)
WCS/BT
Parameters WCS BRS TD-LTE
Frequency
(Bandwidth)
Downlink 2350~2360MHz
2496~2690MHz(FCC)
2500~2690MHz(IC)
Uplink 2305~2315MHz
Input Power
Range @
POI
Power Mode +48~ 0dBm
System
Gain/
Nominal
pass band
gain
Downlink
-11~33dB/43dB (2Watt)
-11~37dB/37dB (5Watt)
-11~43dB/43dB (20Watt)
-11~46dB/45dB (30Watt)
-11~46dB/46dB (40Watt)
Uplink 0~30dB
