ADRF ADXV-HPR - Page 57

Advanced RF Technologies, Inc.
57
Rated mean output power
(DL)
45dBm(30Watt) 46dBm(40W)
Maximum Composite
Output Power(UL)
-15dBm
Noise Figure ≤ 5dB @maximum gain, Center Frequency
VSWR
≤ 1.3:1 @ BTS interface port
≤ 1.5:1 @ Internal interface port
Optical Loss 0~5dBo
System Delay < 2us
Spurious Meet FCC, 3GPP TS 36.104, 3GPP2 C.S0010-C
Dimension
(WXDXH)
Head End
Chassis
19in x 19.7 in x 7.0 inches
POI/POIL 1.3in x 17.0 in x 6.85 inches
ADXV-HPR
Chassis
19in x 15.0 in x 10.5 inches
ADXV-
HPR(Remote
Unit)
2.75in x 17.8 in x 10.3 inches
Weight
Head End
Chassis
20.9 lbs
POI 6.17 lbs
POIL 5.00 lbs
ADXV-
HPR(Remote
Unit) Chassis
17.60 lbs
ADXV-
HPR(Remote
Unit)
13.22 lbs
Operating Temperature -22 - 140 F(-30~60°C)
Operating Humidity 5~90%RH
Power
Supply
Head-End
-48V DC
110/220V, 50-60Hz(optional) with battery backup function
ADXV-HPR
110/220V, 50-60Hz
-48V DC(optional)
Power
consumption
ADXV-H-NMS-
AC
8.85 Watt
ADXV-H-ODU-
4
7.47 Watt
ADXV-H-POI
7.20 Watt
ADXV-H-POIL
6.45 Watt
ADXV-HPR-
PSU-AC
5.4 Watt
ADXV-HPR-
ORU
109 Watt
ADXV-HPR-
45W
255 Watt
