Mounting and Wiring the Control
2-7
AUXILIARY DEVICE CURRENT DRAW WORKSHEET
DEVICE CURRENT # UNITS TOTAL
CURRENT
6150ADT Touchpad 40mA
(70mA alarm)
6160VADT Voice
Touchpad
60mA
(190mA alarm)
6270ADT Touch Screen
180mA/220mA
††
(280mA alarm)
8132ADT iCenter
150mA/350mA
††
(200mA/400mA
††
alarm)
5881/5882 RF Receiver 60mA
5883 Transceiver 80mA
4219 Zone Expander 30mA
4204 Relay Unit
15/180mA
‡
4229 Zone Expander/Relay
Unit
30/100mA
‡
4286 Phone Module 300mA
*
* If using hardwire devices such
as PIRs, refer to the
specifications for that particular
unit's current draw.
†
In UL installations, maximum
current draw from the Auxiliary
Output and the Alarm Output
combined must not exceed
600 mA (500 mA max from
Auxiliary Output).
‡
Figures are for relays
OFF/relays ON.
††
backlighting off/backlighting on
*
*
*
*
*
*
(Current available from Aux. terminals = 600 mA max.)
†
TOTAL =
To Next Page
