ADT SASW3000EN Installation And Setup Guide

5-1
SECTION 5
Zone Programming
( ∗
∗∗
∗ 56 and ∗
∗∗
∗ 58 Menu Modes)
••••••••••••••••••••••••••••••••••••••••••••••••••
About Zone Programming
∗56 Zone Programming is used to program zones, zone types, report codes, enroll 5800 RF Wireless
Transmitter serial numbers, and identify the type of loop input device(s). This mode can also be used
to enter alpha descriptors for programmed zones; however, we recommend entering descriptors in
menu mode ∗82 (Alpha Descriptor Programming after all zone programming has been completed).
For a faster method of zone programming, you can use the ∗58 Expert Programming Mode instead of
∗56 Zone programming. The ∗58 Expert Programming Mode is designed for those who have had
previous experience in programming control panels of this type.
NOTE: Alpha display prompts are shown in a double-line box.
∗
∗∗
∗56 Zone Programming Procedure
Zone Programming involves:
1. Entering the zone number to be programmed;
2. Making appropriate entries at the prompts;
3. Confirming the serial number of wireless transmitter zones.
Start Zone Programming mode by pressing ∗56 while in Data Programming mode. The following
prompts are displayed:
PROMPT VALID ENTRIES EXPLANATION
SET TO CONFIRM?
0 = NO 1 = YES
Set to Confirm
0 = no
1 = yes
If 1 (Yes) is entered, you will be prompted to confirm each
transmitter after entering the serial and loop numbers (at the
“XMIT TO CONFIRM” prompt later in this procedure). We
recommend that you confirm the programming of
every transmitter.
Enter Zn Num.
(00 = Quit) 10
Zone Number
01-08 = wired zones
09-48 = expander/wireless
zones
49-64 = RF button zones†
91 = addressable device
reporting enable
92 = duress report enable
95, 96, 99 = emergency
zones
00 to quit
[∗] to continue
Enter the zone number that you wish to program. Zone 10 has
been entered as an example in the display at left.
Zone 91 is used to enable/disable addressable device
reporting.
Zone 92 is used for duress reporting.
95, 96, 99 are emergency (panic) key zones.
† Each button on a wireless key must be assigned to a unique
zone number. That zone number can then be programmed for
the desired zone response type. Use the Wireless Key
Programming Templates (following the *58 Expert Mode later
in this section) to easily assign buttons to predefined
functions.
