12-1
SECTION 12
AVS System Enable and
Quick Program Commands
•••••••••••••••••••••••••••••••••••••••
AVS Command Procedure
Applies to an AVS system using an ECP connection to the control.
1. Install the AVS module according to its instructions.
2. Use one of the control’s AVS Quick Program commands as follows (see Quick Program Command Results
below for results of each command):
• installer code + [#] + [0] + 3: enable AVS operation without panel sounds on the AVST speaker
• installer code + [#] + [0] + 4: enable AVS operation and enable panel sounds on the AVST speaker
3. Use data field ∗55 Dynamic Signaling Priority to select the desired reporting paths (phone line and/or
GSMV) and path for AAV communication.
4. To undo the Quick Command programming, use the following commands:
• installer code + [#] + [0] + 5: remove all programming options set by [#] +
[0] + 3 quick command
• installer code + [#] + [0] + 6: remove all programming options set by [#] +
[0] + 4 quick command
Quick Program Command Results
When either the #03 or #04 Quick Program command is used, the following are automatically programmed
and no longer available for other control panel purposes.
Pre-Programmed #03 Command #04 Command
Output Function No.
(∗80 mode)
46 (zone type 60, relay 15)
47 (zone type 61, relay 16)
48 (zone type 62, relay 16)
Same as #03 plus:
41 (zone type 14, relay 13)
42 (zone type 22, relay 13)
43 (zone type 39, relay 14)
44 (zone type 33, relay 14)
45 (zone type 36, relay 14)
Output Relay No.
(∗79 mode)
15 (addr 11, relay pos 2)
16 (addr 11, relay pos 1)
Same as #03 plus:
13 (addr 11, relay pos 4)
14 (addr 11, relay pos 3)
Protection Zone
(∗56/∗58 mode)
4229 zn 48 (zt 81, addr 11) Same as #03 command
Device Address address 11 (AVS module) Same as #03 command
Data Field ∗91
AAV enabled AAV enabled
