3000EN Series: Installation Instructions
4-2
FIELD TITLE and DATA ENTRIES EXPLANATION
*27
Powerline Carrier Device (X-10)
House ID
0 = A 6 = G # + 11 = L
1 = B 7 = H # + 12 = M
2 = C 8 = I # + 13 = N
3 = D 9 = J # + 14 = O
4 = E # + 10 = K # + 15 = P
5 = F
Powerline Carrier devices require a House ID, identified in
this field. Program Powerline Carrier devices in interactive
modes ∗79, *80 and *81.
Not intended for fire or UL installations.
*28
Access Code for Phone Module
1-9 = first digit of access code
∗ or # = second digit of access code
(enter # +11 for “∗”, or # +12 for “#”)
You need to assign a 2-digit access code for the 4286 Phone
Module, if used. Example: If desired access code is 7∗ , 7 is the
first entry, and [#] + 11 (for ∗) is the second entry.
NOTE: A “0” in either digit disables the phone module.
Must be “00” for UL Commercial Burglar Alarm installations.
*29
Enable IP/GSM – Communication
Device Menu Mode
(pass-through programming)
Use this Menu mode to program IP/GSM communication
device options. See ∗29 Menu Mode section later in this
document.
Program the radio for device address 3.
Zone Sounds & Timing (
∗
∗∗
∗
31–
∗
∗∗
∗
39)
FIELD TITLE and DATA ENTRIES EXPLANATION
*31
Single Alarm Sounding Per Zone
(per armed period)
0 = no limit on alarm sounding per
zone
1 = limit alarm sounding to once per
arming period for a given zone
Select whether alarm sounding (on the bell output) should be
limited to once per arming period or be unlimited.
SIA NOTE: If “0” selected, “alarm sounding per zone” will be
the same as the “number of reports in armed period” set in
field *93 (1 if one report, 2 if 2 reports, unlimited for zones in
zone list 7).
*32
Fire Alarm Sounder Timeout
0 = yes; fire sounder timeout after time
programmed in field ∗33
1 = no fire sounder timeout; continue
sounding until manually turned off
This control complies with NFPA requirements for temporal
pulse sounding of fire notification appliances.
Temporal pulse sounding for a fire alarm consists of the
following:
3 pulses – pause – 3 pulses – pause – 3 pulses.
UL fire alarm installations: must be 1.
*33
Alarm Sounder Timeout
0 = No timeout 3 = 12 min
1 = 4 min 4 = 16 min
2 = 8 min
This field determines whether the external sounder will shut
off after time allotted, or continue until manually turned off.
UL installations: For residential fire alarm installation, must
be set for a minimum of 4 min (option 1); for UL Commercial
Burglary installations, must be minimum of 16 min (option 4).
*34
Exit Delay
45 - 96 = 45 - 96 seconds
97 = 120 seconds
NOTE: Entries less than 45 will result in a
45-second delay.
The system waits the time entered before arming entry/exit
zones. If the entry/exit door is left open after this time
expires, an alarm will occur. Common zones use same delay
as partition 1.
UL installations: For UL Commercial Burglar Alarm and UL
Residential Burglar Alarm installations with line security,
total exit time must not exceed 60 seconds.
SIA Installations: minimum exit delay is 45 seconds
*35
Entry Delay 1
30 - 96 = 30 - 96 seconds
97 = 120 seconds
98 = 180 seconds
99 = 240 seconds
NOTE: Entries less than 30 will result in a
30-second delay.
Upon entering, the system must be disarmed before the time
entered expires, otherwise it sounds an alarm. Common zones
use same delay as partition 1.
UL installations: For UL Residential Burglary Alarm
installations, must be set for a maximum of 30 seconds; entry
delay plus dial delay should not exceed 1 min. For UL
Commercial Burglar Alarm, total entry delay may not exceed
45 seconds.
SIA Installations: minimum entry delay is 30 seconds
