ADT SASW3000EN Installation And Setup Guide

3-5
Type 25 *
24-Hour Non-Alarm
Monitor
• For use with sensors designed to provide a trouble display (but no trouble
sounding) when an oil tank is low, or other similar application for critical
condition monitoring where a non-alarm response is required.
• When this zone type is faulted and remains faulted for the programmed time
duration (field *53), a special event message is sent to the central monitoring
station. The same holds true for restoration.
Type 77
Keyswitch
• Assign to zone wired to a keyswitch.
• Do not use devices assigned as input type “BR” with this zone type.
Type 81
AAV Monitor Zone
• Assign to zone connected to AAV module.
• Monitors 2-way voice sessions as follows:
- When the zone is faulted, all alarm sounding and dialer reporting stops, except
for fire alarms, which immediately terminate the voice session and cause
a fire report to be sent.
- When the zone is restored (session ended), sounding resumes (if bell timeout
has not expired) and reports that were stopped are sent.
Types 90-93
Configurable
Allows for various custom responses. Options include response to entry/exit delays,
response to opens/shorts, types of alarm/trouble sounding, dial delay, and unique
Contact ID report codes. Types 92 and 93 can only be programmed via downloader.
UL installations: Zone Types 90 – 93 may not be used as fire or burglar alarm zones
on fire or UL burglar alarm installations.
* The system can still be armed when these zone types are in a faulted condition.
NOTE: All of the zone types described are available for the wireless portion of the system, if used.
Mechanics of Programming
To program the system from a touchpad:
• You must use a 2-line Custom English display touchpad.
• Both partitions must be disarmed.
POWER UP NOTE (firmware version display): After powering up, AC, dI (disabled) or “Busy Standby vx.x
Dl will be displayed after about 4 seconds (where vx.x = firmware version). This reverts to a “Ready” message in
approximately 1 minute, which allows PIRS, etc. to stabilize. You can bypass the delay by pressing [#] + [0].
Data Field Programming Procedures
Task Procedure
Entering Program Mode
A) Press both [
∗
] and [#] at the same time within 50 seconds after power is applied
to the control, OR
B) After power-up, enter [Installer code (6321)] + 800 (long beep indicates one of the
partitions is armed and system cannot enter program mode).
(method “B” is disabled if you exit the program mode using
∗
98)
Go to a Data Field
Press [
∗
] + [Field Number] (for example,
∗
21).
A display of “EE” or “Entry Error” means you have entered a nonexistent field.
Simply re-enter [
∗
] plus a valid field number.
Entering Data
When the desired field number appears, simply enter the digits required. The
touchpad beeps three times after the last digit is entered and automatically
displays the next data field in sequence.
If entering less than the maximum digits available (e.g., phone number field), enter
the desired digits, then press [
∗
] and the next data field number to be programmed
to end the entry.
Review a Data Field
Press [#] + [Field Number].
That field’s data is displayed, but no changes can be made.
Deleting an Entry
Press [
∗
] + [Field No.] + [
∗
] (applies only to phone number, account number, and
pager character fields).
Interactive Mode Programming (∗
∗∗
∗56, *57, ∗
∗∗
∗58, ∗
∗∗
∗79, ∗
∗∗
∗80, ∗
∗∗
∗81, ∗
∗∗
∗82, ∗
∗∗
∗29)
Entering Interactive Mode Press [
∗
] + [Interactive Mode No.] (for example,
∗
56) while in Program Mode.
The Custom English display touchpad will display the first of a series of
prompts requesting entries.
After making the appropriate entry, press the [∗] key to accept the entry and
continue to the next prompt.
