ADT SASW3000EN Installation And Setup Guide

14-5
Various System Trouble Displays
Alpha Display Fixed Disp. Meaning
ALARM CANCELED CA
Will appear if an exit or interior zone contained a fault during closing at
the time the Exit Delay ended (e.g., exit door left open), but the system
was disarmed during the Entry Delay time. The alarm sounder and
touchpad sound continuously, but stop when the system is disarmed. No
message will be transmitted to the central station.
EXIT ALARM EA
Will appear when the Exit Delay ends if an exit or interior zone contained
a fault during closing. Alarm sounder and touchpad sound continuously
until the system is disarmed (or timeout occurs). “Exit Alarm” message is
sent to the central station. Also results if an alarm from an exit or interior
zone occurs within 2 minutes after the end of an Exit Delay.
CHECK CHECK
Indicates that a problem exists with the displayed zone(s) and requires
attention.
ALARM 1xx
FAULT 1xx
CHECK 1xx
1xx
1xx
1xx (91)
Indicates that communication between control and a zone expander or
wireless receiver is interrupted, where “xx” is the device address. Check
the wiring and DIP switch settings on the units.
If field *199 is set to “1,” all ECP module problems are displayed as “91.”
If there are wireless sensors in the system, the Check condition may also
be caused by some change in the environment that prevents the receiver
from receiving signals from a particular sensor
SYSTEM LO BAT BAT
With no zone number indicates the system's main standby battery is weak.
LO BAT BAT
With a zone number and a once-per-minute beeping at the touchpad
indicates that a low-battery condition exists in the wireless sensor
displayed (zone “00” indicates a wireless touchpad). If the battery is not
replaced within 30 days, a “CHECK” display may occur.
Some wireless sensors use a non-replaceable long-life battery which
requires replacement of the entire unit at the end of battery life (e.g.,
5802, 5802CP).
TELCO FAULT 94
Telephone Line Failure, indicates that a monitored telephone line (if
programmed in field *92) has been cut or disconnected. Depending on how
the system was programmed, the touchpad may also produce a trouble
sound, and the external sounder may be activated. Silence by entering
installer code + OFF.
Busy-Standby dl
If this remains displayed for more than 1 minute, the system is disabled.
NOTE for CANADIAN PANELS: Power up time is 2 minutes, and CID
code 305 System Reset is sent if the [#] + [0] command is not performed
before the 2 minutes expires.
Modem Comm CC
The system is in communication with the central station for change of
function or status verification.
no display no display
Power Failure: If there is no touchpad display at all and the LEDs are
unlit, operating power (AC and battery) for the system has stopped and
the system is inoperative.
If the message “AC LOSS” (Custom English display) or “NO AC” (English
display) is displayed, the touchpad is operating on battery power only.
If the battery standby capacity is used up during a prolonged AC power
outage, the control's power will shut down to minimize deep discharge of
the battery.
Comm. Failure FC
A communication failure has occurred.
Open Circuit 0C
Touchpad is not receiving signals from the control and sees an open circuit.
Long Rng Trbl bF
Backup LRR communication failure.
Bell Failure 70
Bell supervision failure.
RCVR Jam 90
RF jam detected.
KEYPAD LOW BAT 00 BAT
Wireless touchpad low battery
Phone Okay Cd
The dialer test has been successful (CID code 601).
Dialer Off d0
The dialer is disabled.
Test in Progress dd
Walk test mode is active
Upload Completed dC
the upload or download session was completed
Upload Failed dF
the upload or download session failed before completion
