7-1
SECTION 7
Zone Lists
( ∗
∗∗
∗ 81 Menu Mode)
•••••••••••••••••••••••••••••••••••••••
About Zone Lists
Zone lists let you group individual zones for use with certain system actions. The following table
shows the available zone lists and their purposes:
List No. Used for… Notes
1, 2 general purpose (GP)
3 chime-by-zone (see field *26 to enable option)
4 cross zones (see note at right)
5 night stay zones
6 dial delay disable or GP
7 unlimited reports or GP
8 general purpose
9 zones that activate Pager 1
10 zones that activate Pager 2
11 zones that activate Pager 3
12 zones that activate Pager 4
• Any list may include any or all of the system's zone
numbers.
• A zone list can be assigned to more than one output relay.
• Zone List 4: When creating zone list 4 for cross zoning,
include only zones assigned to zone types 3, 4, or 5. Do not
include zones that have delays (entry/exit zones, interior
w/delay) or 24-hour zones, as these zone types may produce
unpredictable operation and may not function as intended.
See field *85 for Cross Zone Timer option.
• Zone List 6: See field *50 for Dial Delay Disable option.
• Zone List 7: See field *93 for Unlimited Reports option.
Zone List Programming
Zone List programming involves:
1. Selecting an appropriate zone list number;
2. Adding the desired zone numbers to be included in that list.
Start Zone List Program Mode by pressing ✱
81
while in Data Programming mode. The following
prompts are displayed
:
*81 Menu Mode
PROMPT VALID ENTRIES EXPLANATION
Zone List No.
(00 = Quit) 01
Zone List Number
01-12 = zone list number
[∗] to continue
Enter the Zone List Number to program (or 00 to end these
entries). Press [
✱
] to advance.
In the following displays, zone list 01 has been selected for
programming.
01 Enter Zn Num.
(00 = Quit) 00
Zone Number
01-64 = zone numbers
followed by [∗] to
accept each zone
00 to continue
Enter each zone number to add to the zone list, followed by
pressing [
✱
] (example, 01
✱
, 02
✱
, 03
✱
). After all zones are
entered, press 00 to continue.
IMPORTANT: Do not include fire zones in zone lists that are
used to STOP device actions.
01 Del Zn List?
0 = No 1 = Yes 0
Deleting Zone Lists
0 = don’t delete list
1 = delete this zone list
[∗] to continue
To delete the zone list, enter 1. All zones in the zone list will
be deleted automatically and the system returns to the Zone
List No. prompt.
To save the zone list, enter 0.
