FIELD TITLE and DATA ENTRIES EXPLANATION
*80
Output Programming Menu Mode
Use this menu mode to define output functions for use with
output devices/powerline carrier devices. See Output
Programming section for procedures.
*81
Zone List Menu Mode
Use the menu mode to define zone lists. See Zone List
Programming section.
*82
Alpha Descriptor Programming
Menu Mode
Use this menu mode to assign alpha descriptors to zones and/or
create partition descriptors.
*84
Auto-Stay Arm
0 = no
1 = partition 1 only
2 = partition 2 only
3 = both partitions
If enabled, the system will automatically change AWAY mode to
STAY mode if the entry/exit door is not opened and closed
within the exit delay time after a user arms in AWAY mode from
a wired touchpad (non-RF device). An Opening report followed by
an Armed Stay report is sent to the Central Station. If the door
is opened and closed within the exit delay period, the system
remains in AWAY mode.
Any RF device that arms the system AWAY overrides this
feature and the system remains armed in the AWAY mode.
*85
Cross Zone Timer
0 = 15 secs 6 = 2.5 min #+12 = 8 min
1 = 30 secs 7 = 3 min #+13 = 10 min
2 = 45 secs 8 = 4 min #+14 = 12 min
3 = 60 secs 9 = 5 min #+15 = 15 min
4 = 90 secs #+10 = 6 min
5 = 2 min #+11 = 7 min
Sets the maximum amount of time in which two cross zones must
be tripped in an armed system to send an Alarm message to the
Central Station. If only one cross zone is tripped during this
time, a trouble message (CID code 380) for that zone is sent to
the Central Station.
Assign cross zone pairs in zone list 4.
NOTE: Cross zoning takes effect only after Exit Delay expires.
This option not for use in UL installations.
*86
Cancel Verify Touchpad Display
0 = no
1 = yes
When enabled (1 = yes), this feature causes the message
“ALARM CANCELED” to be displayed on the LCD touchpad
under the following conditions:
• After the kissoff of the cancel message to the Central Station,
indicating a successful transmission.
• If an alarm is canceled before the Central Station received the
Alarm message. For example, if an alarm is incorrectly
triggered and the user presses code + OFF before the dial delay
time for the alarm has expired, the message will never go out
to the CS.
•
When the Cancel report is not enabled and the system is
disarmed:
a. before dialer delay expires (alarm report not sent) message
“Alarm Canceled” is displayed.
b. after dialer delay expires “Alarm Canceled” is not
displayed
.
*89
Event Log Full Report Code
0 = no report
1st digit non-zero = send report
If an Event Logging selection is made in field ∗90, a message can
be sent to the central station receiver when the log is 80% full. If
the log becomes full, new messages overwrite the oldest messages
in the log.
*90
Event Log Enables
0 = no event logging
1 = log Alarm/Alarm Restore
2 = log Trouble/Trouble Restore
4 = log Bypass/Bypass Restore
8 = log Open/Close
x = log combination of events (add
value of entries)
This system can record various events in a history log (up to 100
events). The downloader operator can then upload the log and
view or print out all or selected categories of the log. The
downloader operator can also clear the log. Event log can also be
viewed at an alpha touchpad. The display/printout at the central
station will show the date, time, event, and description of the
occurrences.
Data Entry Example: To select Alarm/Alarm Restore” and
“Open/Close”, enter 9 (1+ 8); to select all events, enter #15.
