3000EN Series: Installation Instructions
2-12
Installing a 5800TM Module
1. Mount the 5800TM next to the RF receiver (between one and two feet from the receiver’s
antennas) using its accompanying mounting bracket. Do not install within the control cabinet.
2. Connect the 5800TM to the control panel’s touchpad connection terminals as shown on the
Summary of Connections diagram and set to address 28.
3. For additional information, refer to the 5800TM’s instructions.
Notes
• Use this module only if you are using one or more wireless bi-directional touchpads or keyfobs with
a wireless Receiver; 5800TM is not necessary if using a Transceiver (e.g., 5883).
• The 5800TM must be set to address 28 (cut red-W1 jumper).
• The 5800TM can be used in partition 1 only.
• For additional information regarding the 5800TM, refer to the 5800TM’s instructions.
Installing the Transmitters
1. To be sure reception of the transmitter's signal at the proposed mounting location is adequate,
perform a Go/No Go Test, described in the Testing the System section.
2. Install transmitters in accordance with the instructions provided with each.
3. Set 5827, 5827BD, 5804BD wireless touchpads to the programmed House ID (field *24), using its
DIP switches (5827) or follow the instructions provided with the device.
ULC Note for Canadian Units: In accordance with ULC standards, the RF supervision period for this control is
three hours for Fire zones (Zone Types 9 and 16) and 12 hours for all other zone types.
Notes
• Refer to the table of compatible devices at the back of this manual.
• Supervised transmitters
†
send check-in signals to the receiver at 70-90 minute intervals. If at least
one check-in message is not received from each transmitter within a 12-hour period, the “missing”
transmitter number(s) and “CHECK XX” is displayed.
† Hand-held transmitters (e.g., 5802, 5802CP, 5804, 5804BD, 5827, 5827BD) do not send check-in signals.
U
L
The following transmitters are not intended for use in UL installations: 5802, 5802MN, 5802MN2, 5804BD,
5804BDV, 5804E, 5804WATCH, 5814, 5816TEMP, 5819, 5819WHS & BRS, and 5850.
The 5827BD and 5800TM can be used in UL Listed Residential Burglar installations.
Transmitter Battery Life
• Batteries in the wireless transmitters may last from 4 to 7 years, depending on the environment,
usage, and the specific wireless device being used. Factors such as humidity, extreme
temperatures, as well as large temperature variations may all reduce the actual battery life in a
given installation. The wireless system can identify a true low-battery situation, thus allowing the
dealer or user of the system time to arrange a change of battery and maintain protection for that
given point within the system.
• Some transmitters (e.g., 5802 and 5802CP) contain long-life but non-replaceable batteries, and no
battery installation is required. At the end of their life, the complete unit must be replaced (and a
new serial number enrolled by the control).
• Button-type transmitters (such as 5801, 5802, and 5802CP) should be periodically tested for
battery life.
• The 5802MN and 5804 Button Transmitters have replaceable batteries.
Do not install batteries in wireless transmitters until you are ready to enroll during system
programming. After enrolling, batteries need not be removed.
