3000EN Series: Installation Instructions
5-2
PROMPT VALID ENTRIES EXPLANATION
Zn ZT P RC In: L
10 00 1 10 RF: 1
OR
Zn ZT P RC In: AD
10 00 1 10 AW: 07
OR
Zn ZT P RC HW: RT
10 00 1 10 EL 1
Summary Screen
[∗] to continue
A summary display appears.
“IN: L” appears for wireless zones and indicates input type
and loop.
“IN: AD” appears for hardwire expansion zones (AW) and
indicates the module’s address (AD), which is based on the
zone number.
“HW: RT” appears for hardwire zones and indicates
configuration (EOL, NO, NC ) and response time selection.
10 Zone Type
Perimeter 03
Zone Type (ZT)
(see table at right; types
92/93 only programmable
via downloader)
Each zone must be assigned to a zone type, which defines the
way in which the system responds to faults in that zone.
Enter the Zone Type code from the list below:
Note: If 00 is entered, Delete Zone ? will be displayed.
00 = Not used 07 = 24-Hr Audible 20 = Arm–STAY*
01 = Entry/exit #1 08 = 24-Hr Aux 21 = Arm–AWAY*
02 = Entry/exit #2 09 = Fire 22 = Disarm*
03 = Perimeter 10 = Interior w/Delay
23 = No Alarm Resp
04 = Interior Follower 12 = Monitor Zone 24 = Silent Burglary
05 = Trouble Day/Alarm Night 14 = Carbon Monoxide 25 = 24-Hr Non-Alarm
06 = 24-Hr Silent 16 = Fire w/Verify 77 = Keyswitch
81 = AAV Monitor Zone
*5800 button-type transmitters only 90-93 = Configurable
10 Partition
1
Partition No. (P)
1-3 = partition (3 = common)
[∗] to continue
Enter the Partition number for this zone. Partition 1 is shown
entered.
10 Report Code
1st 01 2nd 00 10
Report Code (RC)
First Digit:
01
†
= enable CID report
00 = disable CID report
Second Digit: entries
ignored
[∗] to continue
Entering any non-zero entry as the first digit enables the
Contact ID report code for this zone. Refer to the System
Communication section for information about report codes
and formats.
† typical entry
02 HARDWIRE TYPE
EOL 0
Hardwire Type
0 = EOL
1 = NC
2 = NO
[∗] to continue
This prompt appears only for zone numbers 02-08.
Zone 1 is automatically set for EOL operation.
02 Response Time
1
Response Time (RT)
0 = 10mSec
1 = 350mSec
2 = 700mSec
3 = 1.2 seconds
[∗] to continue
This prompt appears only for hard-wired zones 01-08 (zone 02
is used as an example in display).
