ADT SASW3000EN Installation And Setup Guide

3000EN Series: Installation Instructions
5-6
PROMPT VALID ENTRIES EXPLANATION
10 INPUT S/N: L
AXXX-XXX –
Serial number
S/N = serial number
L = loop number
[∗] to continue
Manually enter the serial number (found on the transmitter
label), by typing digits in the “X” locations, using the [A]
(advance) or [B] (back) keys as required. You can also perform
two open and close sequences; for button-type transmitters
that means pressing and releasing the button twice.
NOTE: If you want to copy the previous zone’s serial number,
press the [C] key.
Press [✱] to advance to the loop number, then enter loop
number.
Press [✱] to accept the existing serial and loop number and
continue to the “Confirm” prompt below. If necessary, press
[#] to back up and re-enter or edit the serial number.
10 INPUT S/N: L
A000-0000 0
To Delete a Serial
Number
[∗] to continue
To delete an existing serial number, enter 0 in the loop
number field. The serial number will change to all 0's as
shown.
If 0 was entered in error, simply re-enter the loop number,
and the serial number will return to the display.
10 XMIT TO CONFIRM
PRESS ✱ TO SKIP
Confirm
[∗] to continue
The prompt to confirm appears. This prompt will only appear
if the first prompt after entering ✱58 was answered “Yes.” To
confirm, activate the loop input or button that corresponds to
this zone.
The system checks for duplicate. If a duplicate exists, a long
error beep will sound.
Press [#] to back up and re-enter the serial and/or loop
number.
Entd A022-4063
Rcvd A022-4064
If Serial or Loop
Numbers do not match
after activating the
transmitter
[∗] to continue
If the serial/loop number combination transmitted does not
match the serial and loop number entered, a display similar
to the one below will appear. If the loop number does not
match, it will also be displayed. If so, activate the
transmitter’s loop input or button one or more times.
If a match is still not obtained (i.e., summary display does not
appear), press the [#] key twice and enter the correct loop
input or, if correct, press [#] again and then enter the correct
serial number.
Zn ZT P RC In L
10 03 1 10 RF: 1s
Note that an “s”
indicates that a
transmitter’s serial
number has been
enrolled.
Summary Screen
[∗] to continue
01-64 = zone number
00 = quit
If the serial number transmitted matches the serial number
entered, the touchpad will beep 3 times and a summary
display will appear, showing the programmed information for
that zone.
Press [✱] to begin programming the next zone. See first
“Summary Screen” prompt paragraph on previous page.
To quit this mode, press “00” at this prompt.
