ADT Unimode 9600 User Manual

3URJUDPPLQJ 0DVWHU3URJUDPPLQJ/HYHO
 8QLPRGH31&
:KLOHYLHZLQJRQHRIWKH0RQLWRU7\SHVFUHHQVVHOHFWWKHW\SHRIPRQLWRUPRGXOH
EHLQJSURJUDPPHGE\SUHVVLQJWKHFRUUHVSRQGLQJNH\SDGQXPEHUNH\7KHGLVSOD\
ZLOOUHWXUQWRWKH(GLW0RQLWRU6FUHHQZKLFKZLOOVKRZWKHQHZW\SHVHOHFWLRQ
0RQLWRUPRGXOHW\SHVHOHFWLRQZLOODIIHFWWKHIXQFWLRQRIWKHSRLQWDVIROORZV
@@@@MONITOR@TYPE
1=DRILL-SWITCH
2=PAS-BYPASS
3=USER-DEFINED-14
Monitor Type Screen #12
Monitor Type Screen #11
@@@@MONITOR@TYPE
1=ACK-SWITCH
2=SIL-SWITCH
3=RESET-SWITCH
Monitor Type Screen #9
@@@@MONITOR@TYPE
1=POWER-MONITOR
2=TROUBLE-MONITOR
3=USER-DEFINED-12
Monitor Type Screen #10
@@@@MONITOR@TYPE
1=PROC-MON
2=PROCMON-AR
3=USER-DEFINED-13
Note: For the PROCMON-AR selection, PROCMON refers to Process Monitor and AR refers to AutoResettable
Monitor Type Action When Activated
Pull-Station Fire Alarm
User-Defined-1 Fire Alarm
Waterflow Fire Alarm Delayed
User-Defined-2 Fire Alarm Delayed
Monitor Fire Alarm
Blank Fire Alarm
User-Defined-3 Fire Alarm
Future Use Future Use
User-Defined-4 Supervisory on partial short, Fire Alarm on full short
Smoke-Conventional Fire Alarm
Heat-Detector Fire Alarm
User-Defined-5 Fire Alarm
User-Defined-6 Fire Alarm
Medic-Alert Supervisory, latching
User-Defined-7 Supervisory, latching
Hazard-Alert Supervisory, latching
User-Defined-8 Supervisory, latching
Tornado-Alert Supervisory, latching
User-Defined-9 Supervisory, latching
User-Defined-10 Supervisory, latching
User-Defined-11 Supervisory, latching
Tamper Supervisory, nonlatching (tracking)
Supervisory Supervisory, latching
Supervisory-AR Supervisory, nonlatching (tracking)
Power-Monitor AC Fault
Trouble-Monitor Trouble
User-Defined-12 Trouble
Proc-Mon Piezo
Procmon-Auto Piezo, nonlatching (tracking)
User-Defined-13 Piezo, nonlatching (tracking)
Ack-Switch Acts like panel Acknowledge Key
Sil-Switch Acts like panel Alarm Silence Key
Reset-Switch Acts like panel Reset Key
Drill-Switch Acts like panel Drill Key
PAS-Bypass PAS Disable
User-Defined-14 PAS Disable
