3.7.1 Disable Point

Pressing 1 for Point Program, while viewing Maintenance Screen #1 will cause the

following screens to be displayed:

Select the Loop, containing the device to be disabled, by pressing 1 for Loop 1 or 2 for

Loop 2. A screen will then be displayed, allowing the operator to select the type of

addressable device to be disabled as shown in the following display:

Select the device type by pressing 1 for an addressable detector or 2 for an addressable

module. The operator will be prompted to enter the three digit device address as shown in

the following example for a detector:

A flashing cursor will appear in the bottom left corner of the display, prompting for the

three digit device address. When the third digit is enter, 001 for example, a screen will

appear which will allow enabling or disabling of the selected point, as illustrated in the

following example:

Pressing 1 repeatedly will cause the display to toggle between Enabled Yes and Enabled

No.

PROGRAMMING

1=POINT PROGRAM

2=HISTORY

3=PROGRAM CHECK

Maintenance Screen #1

@@POINT@PROGRAM

1=LOOP@1

2=LOOP@2

Loop Select Screen

@@POINT@PROGRAM

1=DETECTOR

2=MODULE

Device Select Screen

@EDIT@DETECTOR

ENTER@POINT@ADDRESS

***

Address Select Screen



EDIT@DETECTOR@1D001

1=ENABLED@@@@@@@@YES

Enable/Disable Select Screen
