5HDG6WDWXV 2SHUDWLQJ,QVWUXFWLRQV

8QLPRGH31& 

Pressing the down arrow key, while viewing the screen shown above, will allow the

operator to view additional programming information about the selected device, such as:

• Enable/Disable Status

• Device Type

• Alarm Verification On/Off

• Walktest Yes/No

• PAS (Positive Alarm Sequence) Yes/No

• Pre-Signal Yes/No

• Zone Assignments (five maximum)

• Adjective/Noun descriptor

4.22.2 Zones

Pressing 2 while viewing Read Status Screen #1 will cause the following screens to be

displayed:

From the preceding screens, the control panel operator can view:

• Zones Installed - all software zones programmed into the system (99 maximum)

• Zones Enabled - all software zones that are enabled

• Zones Disabled - all software zones that have been disabled

• Special Purpose - on or off programming for Special Purpose Zones 97 reserved for

PAS, 98 reserved for Pre-signal and 99 reserved for future use

• Zone Type - the Type assigned to each installed zone (default is Alarm)

READ STATUS

1=SYSTEM POINT

2=ZONES

3=POWER

Read Status Screen #1

ZONES

1=ZONES INSTALLED

2=ZONES ENABLED

3=ZONES DISABLED

Zones Screen #1

ZONES

1=SPECIAL PURPOSE

2=ZONE TYPE

Zones Screen #2
