SECTION 3
Programming
3.1 Programming Data Entry
Programming can be accomplished using the Unimode 9600 keypad or by connecting an
optional standard computer keyboard. The keyboard can be connected to the PS-2
connector J7 on the control panel main circuit board.
The information presented in this section refers to programming the Unimode 9600 via the
onboard keypad. If an optional computer keyboard is connected to the Unimode 9600
main circuit board, the following table describes the keyboard keys which correspond to
the onboard keypad keys.
Note: The main keypad function keys (ACK/STEP, ALARM SILENCE, DRILL and RESET)
are not available on the keyboard.
Keypad Keys Computer Keyboard Keys
1st Event Home
CLR Delete
ESC Esc
RECALL Insert
**
##
A - Z A - Z
0 - 9 0 - 9
(on QZ key)
Space bar
——
//
••
ENTER Enter
To Next Page
