4.22.10 Annunciators
Pressing 1 while viewing Read Status Screen #4 will display the following screens:
Annunciator Screen #1 indicates if Terminal Mode, ACS Mode and UDACT options are
enabled or disabled. Pressing ‘1’ while viewing Annunciator Screen #2 allows the
operator to view the ACS Mode Annunciator addresses which have been programmed into
the control panel.
4.22.11 Printer/PC
Pressing 2 while viewing Read Status Screen #5 will display the following screens:
The display will inform the operator as to whether the control panel is configured for a
printer or a PC. In the example above, PR4800 indicates that the panel is configured for a
printer with a baud rate of 4,800.
READ STATUS
1=ANNUNCIATORS
2=FUTURE USE
3=FUTURE USE
Read Status Screen #4
ANNUNCIATORS
TERM ENABLED YES
ACS ENABLED YES
UDACT ENABLED NO
ANNUNCIATORS
1=ACS ADDRESS
Annunciator Screen #1
Annunciator Screen #2
READ STATUS
1=FUTURE USE
2=PRINTER/PC
3=PRINT
Read Status Screen #5
PRINTER PC
PRINTER PC PR4800
START BIT
STOP BIT
PRINTER PC
DATA BITS
PARITY
To Next Page
