OVERVIEW NetVanta 3000 Series Hardware Installation Guide
28 Copyright © 2006 ADTRAN, Inc. 61200860L1-34L
NetVanta 3205 (AC version)
Shipments of the NetVanta 3205 (AC) include the following items:
• NetVanta 3205 (AC) base unit with attached mounting ears/screws
• ADTRAN OS System Documentation CD
• Quick Start Guide
• Warranty card
• Detachable AC power cord
NetVanta 3205 (DC version)
Shipments of the NetVanta 3205 (DC) include the following items:
• NetVanta 3205 (DC) base unit with attached mounting ears
• ADTRAN OS System Documentation CD
• Quick Start Guide
• Warranty card
NetVanta 3205 Front Panel Design
The NetVanta 3205 front panel is shown below. Front panel LED descriptions are given in Table 1 on page
42.
Figure 7. NetVanta 3205 Front Panel Layout
NetVanta 3205 Rear Panel Design
The NetVanta 3205 AC and DC version rear panels are shown below with a module installed. Appendix A,
on page 75, provides pinouts.
Figure 8. NetVanta 3205 (AC version) Rear Panel Layout
System bundles are shipped with a base unit, a network interface module, and other appro-
priate contents based on the system-level solution ordered.
Option module shipping contents are given in Option Module Shipping Contents on
page 44.
