Option Modules NetVanta 3000 Series Hardware Installation Guide
58 Copyright © 2006 ADTRAN, Inc. 61200860L1-34L
Dial Backup Interface Modules
NetVanta Analog Modem DIM (P/N 1200864L1)
The Analog Modem DIM provides a modem with data rates up to 33.6 kbps for the NetVanta 3000 Series.
This DIM is a plug-on card that connects to the NIM. For installation instructions, refer to Installing Dial
Backup and Network Interface Modules on page 68.
Features and Specifications
Features
• ITU V.90 compliant
•Async
Standards
• EMC - see Electromagnetic Compatibility (EMC) Table on page 7.
• ACTA/FCC Part 68
• IC CS-03
• UL/CUL 60950
Environmental
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Relative Humidity: Up to 95 percent, noncondensing
Physical
• Dimensions: 2.5-inch W x 3.75-inch D
The Analog Modem DIM can be used in two different modes:
1. Backup interface for a primary connection.
2. CONSOLE port for remote dial-in access.
