NetVanta 3000 Series Hardware Installation Guide Option Modules
61200860L1-34L Copyright © 2006 ADTRAN, Inc. 61
NetVanta Serial DIM (P/N 1200886L1)
The NetVanta Serial DIM provides NetVanta products with the ability to interface with external devices
(e.g., Code Division Multiple Access (CDMA) devices and wireless modems), allowing for dial backup
access to the public switched telephone network (PSTN). This DIM is a plug-on module that connects to
the NIM. For installation instructions, see Installing Dial Backup and Network Interface Modules on
page 68.
Features and Specifications
Features
• 5-pin RS-232 interface vial host RJ-45 DBU connector
• Modem flow control support via CTS
• Communications with external model via AT commands
Compliance
• EMC - see Electromagnetic Compatibility (EMC) Table on page 7.
• IEC 60950
• EN 60950
• UL/CL 60950
• AS/NZS 60950
Environmental
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Relative Humidity: Up to 95 percent, noncondensing
Physical
• Dimensions: 2.3-inch W x 2.75-inch D
An RJ-45 to DB-9 adapter cable (P/N 1200887L1) is required to conect to the external
modem.
